◆ Technical parameters: minimum flow rate up to 0.03 l/min, pressure up to 24 bar
◆ Performance characteristics: lightweight structure, measurement accuracy ±1% deviation, stable operation without pulsation, high-quality gear motor
◆ Application: Dosed pumping of low or high viscosity media, with or without solid particles, in the food, environmental and chemical industries
Diameter: DN15–DN1200; Pressure: PN16–PN160, Class150–Class2500; Housing material: WCB, stainless steel 304/316, duplex steel; Connection: flange, threaded, welded, clamp; Drive: manual, pneumatic, electric, hydraulic.
Although reagent dosing plants in the petroleum and petrochemical industries do not directly produce products, they are an indispensable “guardian” and “lubricant” in the entire production chain.
The FSC (single stage, single stroke) PTFE alloy centrifugal chemical pump - hereinafter referred to as "FSC centrifugal pump" - is designed and manufactured in accordance with international standards and based on non-metallic pump technology.
DN25–DN1200; PN16–PN160, Class150–Class900; cryogenic steel LF3, stainless steel; t=-196℃…+120℃, extended rod, flanged and welded connection.
DN15–DN800; PN16–PN100, Class150–Class600; cryogenic steels LF2, 304,316; operating temperature -196℃…+80℃; extended anti-freeze rod, flanged/welded connection.
A magnetic centrifugal pump (hereinafter referred to as a magnetic pump) usually consists of an electric motor, a magnetic coupling and a corrosion-resistant centrifugal pump. Its main feature is the use of a magnetic coupling to transmit power in a completely leak-free manner.
DN20–DN600; PN16–PN160, Class150–Class900; WCB Housing, 304,316; flange/welded connection; membrane pneumatic or electric drive.
DN50–DN2600; PN10–PN63, Class150; cryogenic stainless steel body, special seal for low temperatures; t=-196℃…+60℃, extended rod, wafer and flange versions.
Thanks to the reciprocating movement of the plunger, the working medium is directly sucked in or pumped out. Since the plunger and seal are in direct contact with the fluid, the correct choice of plunger material and seal type will ensure more ideal pump performance during operation.
Technical parameters: capacity up to 100 m³/h, pressure up to 48 bar
The static seal between the suction section, middle section and discharge section of the pump is made of metal seal and double O-ring seal, and the pump shaft seal uses high-performance hemp packing or mechanical seal, which is safe and reliable.
Technical parameters: capacity up to 300 m³/h, pressure up to 48 bar
The DG series segmental multistage centrifugal pumps use tension pins to connect the suction section, intermediate sections and discharge section into a single unit.
Self-priming magnetic pumps of the ZFT series fully combine the advantages of a magnetic pump and a self-priming pump: they have a self-priming function, but at the same time they do not have a shaft seal, they use transmission through a magnetic coupling, which completely eliminates the phenomenon of drip leaks.
DN15–DN1800; PN10–PN320, Class150–Class1500; carbon steel, stainless steel, cast iron; flange, thread, welding; rotary, lifting, disk types.
The AZ series slurry pump is an extension of the HTZ pump product line, which has been successfully developed by our company based on many years of technical experience and taking into account advanced foreign technologies.
