◆ Technical parameters: capacity up to 300 m³/h, pressure up to 48 bar
◆ Эксплуатационные характеристики: используется независимая конструкция подшипниковой опоры для восприятия более высоких нагрузок. Часто применяется вместе с крупными винтовыми насосами или в условиях высокого напора. Can be equipped with various types of drive.
◆ Область применения: перекачка различных сред низкой и высокой вязкости, с твёрдыми частицами или без них, в сточных водах, пищевой промышленности, природоохранной и химической промышленности.
Thanks to the reciprocating movement of the plunger, the working medium is directly sucked in or pumped out. Since the plunger and seal are in direct contact with the fluid, the correct choice of plunger material and seal type will ensure more ideal pump performance during operation.
The length can be individually adjusted from 450 to 1000 mm depending on the depth of the customer's tank.
The fluoroplastic FOB magnetic pump is a chemical process pump that uses the principle of modern magnetic mechanics and transfers force non-contactly using permanent magnets. As the motor rotates, the outer rotor (outer magnetic system) drives magnetic lines of force that pass through the thermowell and cause the inner rotor (inner magnetic system) and impeller to rotate synchronously.
Thanks to the reciprocating movement of the plunger, the working medium is directly sucked in or pumped out. Since the plunger and seal are in direct contact with the fluid, the correct choice of plunger material and seal type ensures more ideal pump performance during operation.
The simple modular dosing unit is a complete plug-and-play dosing device. It is designed, manufactured, assembled and tested at the manufacturing plant in accordance with the customer's technological requirements, and then completely delivered to the site.
The three-chamber solution preparation unit is designed specifically for dissolving and preparing solutions of high molecular weight polymer – polyacrylamide (PAM). Mainly used for flocculation treatment of industrial wastewater, flocculation in sludge dewatering, drinking water treatment, and wastewater treatment in chemical, pulp and paper and other industries.
The static seal between the suction section, middle section and discharge section of the pump is made of metal seal and double O-ring seal, and the pump shaft seal uses high-performance hemp packing or mechanical seal, which is safe and reliable.
SKF bearings, a world famous brand, provide more stable performance.
Technical parameters: capacity up to 100 m³/h, pressure up to 48 bar
The AZ series slurry pump is an extension of the HTZ pump product line, which has been successfully developed by our company based on many years of technical experience and taking into account advanced foreign technologies.
Independent cutting module, good cutting ability, not prone to clogging. If the particles can pass through the suction hole, they will be easily crushed. Transporting lightly contaminated wastewater, cesspools, hospital wastewater and other media containing long and thin fibers. Large particles cannot be transported.
This series of horizontal centrifugal pumps are horizontal, radial split, open back, single stage, single suction volute type centrifugal pumps. The design of the impeller is closed type. The pump body has an axial suction pipe, a discharge pipe located on top, and a foot support.
Equipment for automatic and precise dosing of chemical reagents into circulating cooling water systems, boiler plants or other water systems. Its main purpose is to prevent scale formation, corrosion and biological fouling (algae, bacteria) in the system by dosing certain chemicals, thereby ensuring its safe, stable and efficient operation.
Technical parameters: capacity up to 100 m³/h, pressure up to 48 bar
The DG series segmental multistage centrifugal pumps use tension pins to connect the suction section, intermediate sections and discharge section into a single unit.
Can pump clean water and slightly contaminated water with temperatures up to 40°C and pH 4–10; the maximum diameter of passing particles is 100 mm.
